LEKA Multi-Head Servo Filling Machine Series

Multi-Head Servo Filling Machine

LEKA multi-head servo liquid filling machine series for oil, paste, viscous liquid, large-volume liquid filling, and integrated filling-and-capping projects. Filling head quantity, pump type, PLC and touchscreen configuration, filling range, capping module, conveyor layout, and voltage standard can be customized according to product samples, bottle type, output target, and factory layout.

← Back to Filling Machine Center

Filling Range

20ml-30L, model dependent

Available Heads

4-12 heads, customizable

Filling Method

Servo filling / pump filling

Application

Oil, paste, liquid, viscous product

Overview

The LEKA multi-head servo filling machine series is designed for projects that need stable filling accuracy, repeatable servo control, and flexible model selection across different bottle sizes and product viscosities. The series includes 4-head high-capacity liquid filling, 8-12 head servo oil filling, 6-12 head servo filling, and 6-head servo filling with capping. For complete production planning, this unit can be matched with conveyor, capping, labeling, coding, and downstream packing equipment from the filling machine line.

Multi-Head Servo Filling 4-head, 6-head, 8-head, 12-head, and customized filling-head layouts can be evaluated according to output target, bottle spacing, and site layout.

Oil, Paste and Liquid Applications Available pump configurations include high-precision oil pump, magnetic gear pump, and 316L gear pump for different liquid and viscous product conditions.

PLC and Touchscreen Control Siemens, Delta, and Xinjie control options can be configured with Chinese-English operating interface according to production and operator requirements.

Integrated Capping Option The 6-head filling and capping configuration supports servo lifting and a servo-controlled three-claw capping mechanism when filling and capping need to be combined in one line.

Available Models

GZSF-04-A

4-head high-capacity servo liquid filling machine for larger filling volumes from 5L to 30L, with Siemens PLC and touchscreen operation.

4-head servo 5L-30L Large volume Siemens PLC

GZSF-RHY12-B

8-12 head servo oil filling machine for 100ml to 5000ml filling range, configured with high-precision oil pump and Siemens PLC touchscreen.

8-12 heads Oil filling 100ml-5000ml High output

GZSF-06-C

6-12 head servo filling machine for paste and liquid filling, using high-precision magnetic gear pump with Siemens PLC touchscreen control.

6-12 heads Magnetic gear pump Paste and liquid

YZDGZX-6TSFA

6-head servo filling and capping machine with 316L gear pump, extended anti-drip nozzle, servo lifting, and three-claw servo capping mechanism.

Filling + capping 6-head servo 316L gear pump Three-claw capping

Model Comparison

View Larger

Parameter	GZSF-04-A	GZSF-RHY12-B	GZSF-06-C	YZDGZX-6TSFA	Notes
Machine Name	4-Head Servo Filling Machine	12-Head Oil Servo Filling Machine	6-Head Servo Filling Machine	6-Head Servo Filling and Capping Machine	Names follow the supplied product sheets; final configuration can be customized.
Filling Range	5L-30L	100ml-5000ml	100ml-5000ml	20-1000ml / 500-5000ml	Filling volume should be confirmed with product samples, bottle drawings, and target output.
Filling Speed	240-480 barrels/h	2600-3600 bottles/h	2000-2800 bottles/h	1800-2600 bottles/h based on 500ml reference volume	Actual speed depends on material viscosity, filling volume, bottle shape, and line layout.
Applicable Materials	Large-volume liquid filling	Oil, paste and liquid	Paste and liquid	Liquid preparations, viscous liquids, oils	Material compatibility should be reviewed before final machine selection.
Filling Method	Servo liquid filling	Servo oil filling with high-precision oil pump	Servo filling with high-precision magnetic gear pump	Servo filling with 316L high-precision gear pump	Pump and nozzle configuration are selected according to viscosity and dosing requirement.
Control System	Siemens PLC + touchscreen	Siemens PLC touchscreen	Siemens PLC touchscreen	Delta 7-inch touchscreen; Xinjie PLC driver; Siemens or Xinjie option available	PLC and HMI brands may be adjusted according to project specification and availability.
Capping Configuration	Filling machine; capping integration optional	Filling machine; capping integration optional	Filling machine; capping integration optional	Three-claw servo capping with servo lifting	Capping suitability depends on cap type, bottle neck, torque requirement, and cap feeding method.
Power	3.2 kW	7.5 kW	4.0 kW	Project confirmation required	Power value may change after customization of pump, head quantity, conveyor, or capping module.
Machine Size	400 × 105 × 175 cm	600 × 105 × 175 cm	400 × 95 × 175 cm	8m × 1.2m × 1.7m	Shown as L × W × H; final layout should be checked with the factory floor plan.
Line Integration	Can connect with conveyor, capping, labeling, and packing equipment	Can connect with conveyor, capping, labeling, and packing equipment	Can connect with conveyor, capping, labeling, and packing equipment	Integrated filling and capping structure with downstream connection option	LEKA can review upstream and downstream connection with complete filling line requirements.

Key Component Specifications

View Larger

Component	Configuration	Notes
PLC Controller	Siemens / Delta / Xinjie	PLC brand is selected according to model configuration and project requirement.
Touchscreen HMI	Delta 7-inch / Siemens / Xinjie	Chinese-English operating system can be configured according to operation requirement.
Detection Sensor	Panasonic / SICK	Used for bottle detection, filling position control, and line stability.
Pump	316 / 316L gear pump, high-precision oil pump, or magnetic gear pump	Pump type should be confirmed according to viscosity, filling volume, and material compatibility.
Filling Nozzle	316L precision-machined extended nozzle with anti-drip pneumatic control	Anti-drip design is recommended for oil, viscous liquid, and products that affect workshop hygiene.
Pneumatic Solenoid Valve	Airtac / Star	Configured for pneumatic actions such as anti-drip control and related cylinder movements.
Switching Power Supply	Taiwan Mean Well	Electrical configuration should match the project voltage standard.
Voltage	220V / 50Hz	Other industrial voltage standards should be confirmed before production.
Air Pressure	0.4-0.6 MPa	Stable compressed air supply is required for pneumatic control.
Conveyor Belt Motor	750W with frequency converter	Conveyor speed can be adjusted to match filling and capping rhythm.
Lifting Servo	Xinjie / Jiemeikang	Used for controlled lifting motion in filling or capping sections where required.
Capping Mechanism	Servo-controlled three-claw capping mechanism	Applies to the 6-head servo filling and capping model; final design depends on cap sample.

FAQ

Which model is suitable for large-volume liquid filling?

GZSF-04-A is the 4-head high-capacity servo liquid filling model for 5L to 30L applications. Final selection should still be checked with bottle size, product flow behavior, and target output.

Which model should be used for edible oil or oil products?

GZSF-RHY12-B is designed as an 8-12 head servo oil filling machine with a 100ml to 5000ml filling range and high-precision oil pump. Oil viscosity, bottle size, and anti-drip requirement should be confirmed before quotation.

Can this series fill paste and viscous liquid?

Yes. GZSF-06-C is listed for paste and liquid applications with a high-precision magnetic gear pump. YZDGZX-6TSFA can also handle liquid preparations, viscous liquids, and oils depending on product testing.

Does LEKA offer filling and capping in one machine?

Yes. YZDGZX-6TSFA is a 6-head servo filling and capping machine with servo filling, servo lifting, and three-claw servo capping. Cap type, bottle neck, and capping torque should be confirmed with samples.

Can the filling head quantity be customized?

Yes. Filling-head quantity can be customized according to required bottles per hour, filling volume, bottle spacing, conveyor layout, and available installation space.

What information is needed for quotation?

Please provide product name, viscosity, filling volume, bottle size and photos, cap type if capping is required, target output, automation level, voltage standard, and available installation space.
