LEKA-ZR15 is a straight line hot melt adhesive labeling machine for PET, PP and PE round bottle wrap-around labeling with OPP film, pearl film, paper-plastic composite film and similar roll-fed label materials. It is suitable for washing, beverage, mineral water, food and similar industries that need stable inline labeling and reduced packaging material cost.
Use this section to judge whether the machine fits your product, container, speed target, and line integration plan.
Uses continuous label cutting, glue application and bottle labeling for roll-fed wrap-around label materials.
Catalog output reaches 15000 BPH and can be connected with filling lines to support continuous production.
Catalog range covers 30-86mm bottle diameter and 70-360mm bottle height for common PET, PP and PE round bottles.
HMI can display machine status, output, hot melt adhesive temperature and glue application temperature for easier operation.
Manual start and jog functions help during commissioning, standard changeover and troubleshooting.
The template now displays the real compatibility fields from the equipment backend instead of only showing a generic labeling machine layout.
Suitable for round bottles and cylindrical containers requiring straight-line hot melt adhesive wrap-around labeling. Used for water, beverage, daily chemical, and similar bottle packaging lines where roll-fed film labels and continuous inline labeling are preferred.
Labeling stage after filling and capping, with optional connection to coding, inspection, conveying, collection, and downstream packaging equipment.
Bottle shape, label position, label material, label roll size, and coding integration decide the final labeling structure.
Wrap-Around Labeling
Straight-line hot melt adhesive wrap-around labeling around round bottles and cylindrical containers, suitable for roll-fed film label application in inline production.
Roll-fed OPP labels, pearl film labels, paper-plastic composite film labels, and similar hot melt adhesive label materials for round bottles.
Label height 15-150mm. Label length is configured according to bottle diameter and wrap-around labeling requirements.
Round Bottle
±1mm
Roll-fed OPP or film label roll specification is configured according to label material, bottle diameter, roll diameter, and production speed.
Sample Testing Recommended
Values are shown from the equipment backend. Final configuration should be confirmed with product samples, container drawings, output target, and destination voltage.
This section uses the fields that were hidden in the old template, so buyers can understand not only the machine, but also daily operation and project support.
Changeover depends on bottle size, product format, and connected equipment.
Cleaning method can be confirmed according to product contact parts and production schedule.
Changeover should confirm bottle diameter, bottle height, label width, label length, roll size, hot melt adhesive temperature, glue application temperature and guide/star wheel parts.
Recommended spare parts can be prepared according to the final machine configuration.
1 operator for regular operation; additional support may be needed during product changeover, sample testing, or line adjustment.
Safety protection can include emergency stop buttons, overload protection, sensor-based product detection, missing-label or no-product no-label control, protective covers for key moving parts, and line stop coordination with upstream or downstream equipment when integrated into a complete packaging line.
Optional configurations include roll-fed label handling, hot melt glue system configuration, bottle feeding and separating device, label cutting adjustment, conveyor connection, inspection device, reject device, and integration with high-speed bottle packaging lines.
LEKA Pack Line supports each packaging project from early configuration review to after-sales follow-up. Before production, we help review the customer's product type, container samples, filling volume, output target, voltage, cap type, labeling method, automation level and factory layout, so the machine or full line configuration matches real production needs. Before shipment, we can support sample confirmation, factory testing, test videos, export document coordination and spare parts preparation. After the machine arrives, support includes installation and commissioning videos, operator guidance, remote video diagnosis, troubleshooting assistance, spare parts dispatch and after-sales follow-up. Each machine includes a one-year free replacement service for damaged non-consumable spare parts from the date the customer signs for receipt of the machine, excluding normal wear parts, consumables and damage caused by improper operation. When needed, on-site technical service can also be discussed according to the project situation.
This machine can be matched with upstream and downstream equipment according to your product, bottle, cap, label, output, and factory layout.
LEKA-BU is a bottle unscrambler and bottle receiving machine for feeding empty bottles into an automatic packaging line. The turntable uses variable-frequency stepless speed control so...
The LEKA-CE cap elevator is used to lift different cap types from the lower hopper to the cap collection or sorting section of an automatic capping...
LEKA-CW is an inline checkweigher for automatic weight detection, upper and lower limit judgment, and overweight or underweight rejection in packaging lines. It can be matched...
LEKA-ZR15 is an automatic straight line hot melt adhesive labeling machine for roll-fed wrap-around labeling on round bottles. This draft uses the catalog data supplied by the user, with legacy source branding and contact details excluded.
Please provide bottle shape, label width, label length, label roll direction, label material, labeling position, and target line speed.
Suitability should be confirmed with your product type, container shape, size, cap or label requirement, output target, and factory layout. LEKA can review samples or drawings before quotation.
Yes. This equipment can be configured for line integration with filling, capping, labeling, coding, conveying, collection, and end-of-line packaging machines according to the project.
Please send product details, bottle or container photos, size drawings, target output, voltage, automation level, and the process you want to connect before and after this machine.
Yes. Custom options can be reviewed according to samples, required speed, product properties, container size, line direction, available workshop space, and budget.
LEKA engineers will review your product, bottle, cap, label, output, automation level, and factory layout, then recommend a suitable machine or complete line configuration.
To confirm the product shape, standing stability, feeding direction, and suitable labeling structure.
To check bottle diameter, height, width, thickness, or flat surface size for machine adjustment and fixture design.
To confirm label width, length, roll format, adhesive type, sensor selection, and labeling accuracy.
To confirm whether the project needs wrap-around labeling, single-side labeling, double-side labeling, top labeling, corner labeling, or print-and-apply labeling.
To match the correct machine structure, conveyor layout, label head configuration, and upstream/downstream line speed.
To confirm voltage, frequency, machine footprint, conveyor direction, and connection with filling, capping, coding, inspection, or collection equipment.
