LEKA-LB070P

LEKA-LB070P Instant Printing Labeling Machine

LEKA-LB070P combines flat labeling with online printing. It can be configured to print production date, shelf life, barcode, QR code and similar variable information before label application.

Labeling Machine AutomaticLine Integration
LEKA-LB070P Instant Printing Labeling Machine
±1mm
Accuracy

Key Advantages

Why customers select this labeling machine.

1

Online Print-and-Apply

Supports online printing of production date, shelf life, barcode, QR code and other variable information.

2

Flat and Corner Labeling Use Case

The supplied catalog identifies the model as an instant printing labeling machine for corner-label applications.

3

Industrial Print Engine

Catalog reference lists Zebra ZE511 as a selectable print engine, with 203dpi standard and 300dpi available.

4

Stable Label Feed Structure

Double pressure rollers and segmented clutch design help maintain label tension during print-and-apply operation.

5

Servo and Sensor Control

Servo label feeding and sensitive sensors support accurate label placement.

6

Variable Data Connectivity

Catalog reference lists serial, parallel, network, wireless, USB and optional control port configurations according to actual needs.

Product Fit

What this labeling machine can run, and where it sits in your line.

Suitable Products

Suitable for print-and-apply labeling, corner labeling, barcode labeling, QR code labeling, date labels, batch labels, and variable information labels on boxes, cartons, flat packages, and selected containers. This instant printing labeling machine is used where flat surface labeling or corner seal labeling needs online printed label content.

Line Position

Labeling stage after filling and capping, with optional connection to coding, inspection, conveying, collection, and downstream packaging equipment.

Bottle Shapes

Square BottleFlat BottleIrregular Bottle

Labeling Methods

Single Side LabelingTop LabelingCustom Labeling

Technical Specifications

All values are reference configurations and may be adjusted to match your samples and destination voltage.

Production

Output Range
Up to 60 pc /min. Actual output depend on print content, label ize, and product handling.
Line Position
Labeling tage after filling and capping, with optional connection to coding, in pection, conveying, collection, and down tream packaging equipment.
Labeling Type
Single Side Labeling, Top Labeling, Cu tom Labeling
Labeling Accuracy
±1mm

Labels

Label Position
Print-and-apply flat urface labeling, corner eal labeling, barcode labeling, QR code labeling, date labeling, batch labeling, and variable information label application.
Label Material
Self-adhe ive thermal label , paper label , PP label , PET label , barcode label , QR code label , and print-and-apply pre ure- en itive label .
Label Size Range
Label width up to 104mm; label length up to 200mm. Cu tom print-and-apply label ize can be reviewed according to print content and product urface.
Label Roll Spec
Label roll inner diameter: 76mm / 76.2mm; maximum outer diameter: 330-380mm, depending on printer and labeling configuration.

Compatibility

Applicable Bottle Shape
Round Bottle, Square Bottle, Flat Bottle, Irregular Bottle
Date Code Integration
Sample Te t Required

Electrical

Power / Voltage / Air
Catalog priority: 220V / 50Hz / 2000W. Text reference li t 220V / 50Hz / 1500W; catalog i u ed a the newer ource.

Additional

Machine Model
LEKA-LB070P
Machine Type
In tant printing labeling machine / print-and-apply flat labeler
Applicable Products
Square, round and flat- urface product requiring online printed label
Production Speed
Up to 60 pc /min
Label Max Width
104mm, cu tom de ign according to cu tomer requirement
Label Max Length
200mm, from upplied text reference
Label Roll Inner Diameter
Catalog value: Φ76.2mm. Text reference li t φ76mm.
Label Roll Outer Diameter
Catalog value: Φ380mm. Text reference li t Φ330mm.
Outline Size
L2000 × W1000 × H1700mm
Equipment Weight
400kg, from catalog
Power Supply
Catalog priority: 220V / 50Hz / 2000W. Text reference li t 220V / 50Hz / 1500W; catalog i u ed a the newer ource.
Print Engine Type
Zebra ZE511, electable according to actual need
Print Resolution
203dpi tandard, 300dpi available
Print Speed
203mm/ ec at 203dpi; 203mm/ ec at 300dpi
Maximum Print Width
4.1 inche / 104mm
Backing Paper Width
0.625-4.5 inche / 16-114mm
Minimum Label Length
0.5 inch / 13mm with rollback; 0.25 inch / 6.5mm without rollback
Maximum Print Length
39 inche / 990mm
Maximum Continuous Media Print Length
150 inche / 3810mm
Media Roll
Outer diameter le than 200mm, inner diameter 76mm / 3 inche
Communication Ports
Standard IEEE1284 parallel port and RS232 erial port; network RJ45, wirele and USB electable according to catalog reference
Control Port
RS485 or RS422 optional
Use Environment
Temperature 5-40°C, humidity 15-85% non-conden ing
Barcode System
One-dimen ional and two-dimen ional barcode including Code 11, Code 39, Code 93, Code 128, EAN, UPC, DataMatrix, QR Code, PDF417, Aztec and other li ted in the upplied catalog reference
Working Principle
The printer print variable information onto the label, and the labeling y tem applie the printed label onto the product urface. Stored-label printing and real-time print-and-apply mode have different output range .
Container Range
Square, round and flat- urface product requiring online printed label . Confirm label ize, print content, barcode type, product path and application po ition before production.
Supported Bottle Types
Square, round and flat- urface product requiring printed label application.
Supported Cap Types
Not cap- pecific. Thi model i elected by product hape, label po ition, label ize and line peed.
Supported Label Positions
Flat urface labeling and corner-label print-and-apply application , according to upplied catalog title.
Air Requirement
Air ource requirement i not li ted in the upplied reference. Confirm compre ed air need if optional pneumatic or rejection module are elected.
Machine Dimensions
L2000 × W1000 × H1700mm
Factory Layout Requirements
Re erve pace for product feeding, label roll loading, operator acce , electrical cabinet, conveyor connection and optional printing or in pection tation . Final layout hould match up tream and down tream equipment.

Operation & Support

Day-to-day operation, maintenance, and project support.

Maintenance Points

Confirm product size, product thickness or stability, label width, label length, label position, line speed and feeding direction before changeover.

Operators Required

1 operator for regular operation; additional support may be needed during product changeover, sample testing, or line adjustment.

Safety Protection

Safety protection can include emergency stop buttons, overload protection, sensor-based product detection, missing-label or no-product no-label control, protective covers for key moving parts, and line stop coordination with upstream or downstream equipment when integrated into a complete packaging line.

Custom Options

Optional configurations include paging feeder, product pressing device, corner labeling setup, edge labeling support, coding or print-and-apply unit, barcode or QR code printing, vision inspection, reject device, and custom conveyor layout.

After-Sales Support

LEKA Pack Line supports each packaging project from early configuration review to after-sales follow-up. Before production, we help review the customer's product type, container samples, filling volume, output target, voltage, cap type, labeling method, automation level and factory layout, so the machine or full line configuration matches real production needs. Before shipment, we can support sample confirmation, factory testing, test videos, export document coordination and spare parts preparation. After the machine arrives, support includes installation and commissioning videos, operator guidance, remote video diagnosis, troubleshooting assistance, spare parts dispatch and after-sales follow-up. Each machine includes a one-year free replacement service for damaged non-consumable spare parts from the date the customer signs for receipt of the machine, excluding normal wear parts, consumables and damage caused by improper operation. When needed, on-site technical service can also be discussed according to the project situation.

Common Questions

Quick answers buyers usually ask before requesting a project quote.

How do I choose the right labeling machine configuration?

Configuration depends on your product properties, container, output target, accuracy requirement, and line layout. Sample testing is recommended for special products.

Is this machine suitable for my product and container?

Suitability should be confirmed with your product type, container shape, size, cap or label requirement, output target, and factory layout. Samples or drawings can be reviewed before quotation.

Can it be connected with a complete packaging line?

Yes. This equipment can be configured for line integration with filling, capping, labeling, coding, conveying, collection, and end-of-line packaging machines according to the project.

What information should I send before quotation?

Please send product details, bottle or container photos, size drawings, target output, voltage, automation level, and the process you want to connect before and after this machine.

Can LEKA customize the machine?

Yes. Custom options can be reviewed according to samples, required speed, product properties, container size, line direction, available workshop space, and budget.
